Product code
6010
Technical
Full details
We used our 30 years expeience working with some of the biggest names in the leisure to design a channel profile and standard system to perfectly meet the demands of a busy gym, fitness club, changing room or pool area.
Various options are available to adapt the standard design including channel designs to suit a vinyl floor finish, perforated gratings and side outlet gullies.
For further information please call us on 01952 588488
| Floor Finish | Concrete/Tiled/Resin | Vinyl |
| Drainage channel profile | 6010 | 6051 |
| Grating Type |
Heelsafe Grating. 47 x 5mm open mesh, 12 x 3mm load bar. OR Perforated grating with 8mm diameter laser cut holes. |
|
| Gully Type | 5150 / 5200 | |
| Built in Fall | 1:100 | |
| Material Options | Grade 304 stainless steel or Grade 316 stainless steel in areas where chlorine is present. | |
| Standard Width | 180mm wide x 150mm Grating | |
| Non-Standard Width | Require a non standard width? No problem, Contact one of our sales team for further information. | |
| Applications | Perfect for leisure centres, gyms and swimming pools. | |
Technical
Technical Support
Please email sales@componentdevelopments.com
A thin stainless steel channel that doesn't require any grating
Challenge: To provide a sustainable, effective drainage solution to manage to water run off from shower areas, whilst keeping in line with the industrial design theme.
Challenge: To work alongside Fitness First's in-house engineering department to design the optimum drainage solution.
Challenge: To design, manufacture and supply a high performance, durable stainless steel floor drainage solution for these up and coming gyms.
